Transmitter (Deltabar): HART PROFIBUS PA FOUNDATION Fieldbus
Hazardous area approvals
Transmitter (Deltabar): ATEX FM CSA IEC TIIS NEPSI
Product headline
Calculated volume or mass flow measurement. dp primary element (orifice). Special designs.
Sensor features
Internationally standardized. Nominal pipe size DN10...2000 ; 3/8...80". Meter runs. Weld-In versions. Compact or remote design. Optimizable for minimized pressure loss, improved uncertainty or maximized Turndown. Deltabar S/M differential pressure transmitter.
Nominal diameter range
DN 10...2000 3/8" ... 80"
Max. measurement error
typically < 1% of calculated volume or mass acc. ISO5167 without calibration. Uncertainty of primary element excluding uncertainty of density or compensation.
Transmitter (Deltabar): HART PROFIBUS PA FOUNDATION Fieldbus
Hazardous area approvals
Transmitter (Deltabar): ATEX FM CSA IEC TIIS NEPSI
Product headline
Calculated volume or mass flow measurement. dp primary element (orifice). Special designs.
Sensor features
Internationally standardized. Nominal pipe size DN10...2000 ; 3/8...80". Meter runs. Weld-In versions. Compact or remote design. Optimizable for minimized pressure loss, improved uncertainty or maximized Turndown. Deltabar S/M differential pressure transmitter.
Nominal diameter range
DN 10...2000 3/8" ... 80"
Max. measurement error
typically < 1,5% of calculated volume or mass acc. ISO5167 without calibration. Uncertainty of primary element excluding uncertainty of density or compensation."
Deltatop DV61S, DN61S, DN62S, DO69S, DR61S
Technische Information
Technical Information (TI)
German version - 04/2012
New version available in English
Universelle Differenzdruck-Durchfluss-Messsysteme Mit Venturirohren, Düsen, Blenden und Differenzdrucktransmitter Deltabar S/M. Druckreduzierung durch Drosselblenden
